All In One Solar Street Light

5W Solar Street Light,All In One led Solar Street Light,All In One Solar Light

  • JCN New Energy Technology Co., limited Supply All In One led Solar Street Light,All In One Solar Light,5w Solar Street Light
contact now datasheet
    • Features & Benefits
    • Specifications

 All in one solar street/garden light (5W)
Solar panel Max power 18V10W (high efficiency monocrystalline silicon)
Life time 25 years
Battery Type 7.4V 4AH (Lithium iron phosphate Battery),brand:mottcell
Life time 5 years

LED Lamp

(with sensor)

Max power 12V 5W
Led chip brand Epistar  with high brightness
Lumen (LM) 625-650lm (125-130lm/w)
Life time 50,000hours
Viewing Angle 120°
Controller specifications 12V 5A
MPPT intelligent controller,light and time control,auto ON/OFF
Overload Protection;Over Charging Protection;Over Discharge protection
Short circuit protection;Anti reverse polarity protection
Cutting off by itself;Anti pouring charge;Anti thunder
Accessories For installation Installation bracket/Nuts/Bolts
Charge time By sun 6 hours
Discharge time Full power 12 hours
Half power 24 hours
Working Temperature Range(  ) -30~+70
Colour temperature Range(k) 6000-7500k (can customized)
Mounting height Range (m) 2.5-3m
Space between light Range (m) 7-9m
Lamps material of main Aluminium alloy
Certificate CE / ROHS / IP65
Warranty period 2 years
Packing & Weight Product size 480*280*55mm Corton size 500*570*370mm
Product weight 4.5kg GW.for corton 22kg
Packing box neutral Q'ty/ctn 4sets/ctn
Packs Containers 20GP 1080pcs 40GP 2250pcs
