Off Grid Solar System

50KW Solar System,50KW Off Grid Solar System

  • Shenzhen JCN company supply 50kw solar system,50kw off grid solar system
contact now datasheet
    • Features & Benefits
    • Specifications

Technical Parameter

Model

T50K0384-200

Rated output power

50000w

Battery voltage

DC384V

Solar controller

384V/200A

Solar PV module maximum voltage

≤700vdc

AC output voltage

General:AC380v±3%;50Hz±1Hz

Output wave

Pure sine wave

Plug

Internationalgeneral (Can be selected by customer)

Conversion efficiency

88%

City electricity complementary function

NO(can add this function)

Overload protection

Yes

Low voltage protection

Yes

Overheat protection

Yes

Short-circuit protection

Yes

Battery electric power display

Yes

Charging function of city electricity

NO(can add this function)

Output isolation

Yes

System configuration



Accessory name

Model details

1

 Inverter

3 phase 380V/50Kw

2

Controller

384v200a

3

Solar panel

Mono solar panel 250w*200pcs

4

Bracket

1 set

5

Lead-acid battery

12v200ah*96PCS

6

Cable,Battery connection line

Cable,Battery connection line



System equipment weight、Size

Inverter weight、Size(L*W*H)

550kg*1set  、800*670*1550mm

Controller box weight、Size(L*W*H)

32.5kg*1set、500*330*805mm

Solar PV module weight、Size(L*W*H)

24.5kg*200PCS、1650*986*40mm

Battery weight、Size(L*W*H)

     55.5kg *96PCS 、505*265*235mm

System total weight





Generating capacity(solar PV module power rate*6hours sunshine time*80%)

The average daily sunshine time≥6 hrs area it's generating capacity is≥240kwh
