On Grid Solar System

10KW On Grid Solar System, Solar System On Grid

  • JCN company provide 10kw on grid solar system, solar system on grid for homne use
contact now datasheet
    • Features & Benefits
    • Specifications
NO. Item Specification QTY Unit
1

Poly PV modules

 (1) the installation way: the bracket and the clamp fixed installation

(2)With junction box & 900mm solar cable

JCN-P263W-30V(1640*990*35) 38 pcs
2

Grid-tied inverter

 (1)Installation:wall-mounted type

(2)GPRS,Three-phase double circuit

10KW (pure sine wave)                1 set
3

AC distribution box

 (1)Three-phase with meter

Wall-mounted & waterproof  outdoor use 1 set
4

Photovoltaic cable (DC)

 (1)From solar PV module to inverter

PV1-F 4mm - PV cable(black&red) 60 m
5

AC solar cable

 (1)From inverter to AC distribution box

RV6mm red、red、red/RV4MM black、yellow、green each of 50 m
6 Male female connector  MC4 connector 5 pair
