Portable Solar System

40W Portable Solar System,40w Solar Briefcase,Solar Briefcase

  • Shenzhen JCN New Energy Technology Co., limited Supply Solar Briefcase,40w Solar Briefcase,40w Portable Solar System
contact now datasheet
    • Features & Benefits
    • Specifications









Specification Of Portable Solar System

Charging source

≤100W 18V solar panel( No load 21.5V)

≤5A 15V adapter

Inverter

DC12V-AC220V , 300W pure sin wave

Output voltage

1pc USB 5V 1A output;1pc DC 12V5A output;

1pc DC 12V5A cigarette lighter output; 1pc AC 220V output,maximum output current:2A

Built

in battery

2pcs 12V/24AH(Lead acid battery)

Charging time

Will depends on way of charging and power of solar panel and adapter

Discharging time

Will depends on which load power.

Rated charging current

<10A

Rated discharging current

5A

System voltage

12V

No load loss

<50mA

Over pressure protection

14.4V

Boost voltage

15V

Under voltage

11.6V

Over discharge voltage

10.5V

Control mode

Charging; PWM;

Working temperature

-150C to +650C

Over load and short-circuit protection

10ms response

Protection circuit:

Over load and short-circuit protection

Fuse burnout

                                         Note:System configuration base on real object
